Spirulina Herb Extract High Speed Centrifugal Spray Dryer 120-300C Temp
|Place of Origin:||China|
|Certification:||SGS, CE, ISO|
Payment & Shipping Terms:
|Minimum Order Quantity:||1unit|
|Packaging Details:||shipping container|
|Delivery Time:||25 working days|
|Payment Terms:||L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram|
|Supply Ability:||1000unit per year|
|Name:||High Speed Centrifugal Spray Dryer||Material:||SUS 304, SUS316L|
|Nozzle:||Centrifugal Atomizer||Evaporation Capacity:||10KG/HOUR|
|Heating Source:||Electricity||Packing:||20GP Container|
|Output Capacity:||Depends On Solid Content||Temperature:||120-300|
Spirulina Herb Centrifugal Spray Dryer,
300C Centrifugal Spray Dryer
LPG - 10 High Speed Centrifugal Spray Dryer For Milk Stevia Spirulina Herb Extract
Spray dryer Description
LPG high-speed centrifugal Spray Dryer is applicable for the emulsion, suspension, paste and liquid solution. In polymers and resins, fuels, paints, ceramics, glass type, descaling agent, insecticide, carbohydrates, dairy products, detergents and surfactants, fertilizer, organic compounds and inorganic compounds of dry material, the performance is particularly remarkable. This drier can be widely used into pharmaceutical, chemical, foodstuff and so on industries/field
Spray dryer is also called spray drying machine; Spray dryer is used for small industrial production purpose or for doing experiment, for lab; Big type spray dryer is for mass industrial production of milk powder, protein, blood, chemical, herbal extract, etc
The high speed centrifugal spray dryer is a kind of continuous-pressure drier. A special device is used to spray liquid material into a fog, which is dried by contacting the hot air. Used to dry some of the heat-sensitive liquids, suspensions and viscous liquids, such as milk, eggs, tannins and drugs.
Also used for drying fuel, intermediates, soap powder and inorganic salts.
Features Drying speed, material liquid after atomization surface area greatly increases, in the hot air airflow, instantaneous can evaporate 95%-98% of water, complete drying time only a few seconds, especially suitable for the drying of heat-sensitive materials. The product has good uniformity, fluidity and solubility, high purity and good quality. The production process is simplified and the operation control is convenient. For the moisture content of the series (special materials up to 90%) of the liquid can be dried into a powder product, after drying do not need to crush and screening, reduce production processes, improve product purity.
For the product size, pine density, moisture, in a certain range can be changed operating conditions to adjust, control and management are very convenient.
Drying Machine Classification Working principle The air is filtered and heated into the air distributor on the top of the dryer, and the hot air enters the drying chamber uniformly in a spiral shape. The high-speed centrifugal atomizer on the top of the material liquid is sprayed into a very fine mist liquid bead, which can be dried into a finished product in a very short period of time with the hot air and flow contact. The finished product is continuously exported from the bottom of the drying tower and the cyclone separator, and the exhaust gas is drained by the air blower.
This spray drier is widely used in chemical industry, pharmaceutical industry, foodstuff industry and so on.
1. Material name
2. Content of solid; Content of moisture(%)
3. Processing capacity; Evaporation capacity? (kgs/hour; Litre/ hour)
4. Max. Temperature the material can bear
5. Heating source. Do you need Electric heating compensation to improve heating temperature?
Spray dryer TECHNICAL PARAMETERS spray dryer
|Spray dryer Parameter|
|Water evaporation capacity(kg/h)||5||10||15||20||25||50||100||150||200||500||800||1000||200||3000||4500||6500|
|Diameter of atomizing tray (rpm)||50||80||80||120||150||180-210||Decidedin accordance witn the requirementsof processs|
|Max Electric heating power(kw)||12||24||36||45||46||63||81||99|
|Dried powder restoring rate(%)||≥95|
|Length of convered area (m)||1.6||2.7||3||3.5||4||4.5||5.2||7||7.5||12.5||13.5||14.5||Decided in accordance the flow chart,|
|Width of convered area (m)||1.1||1.5||1.8||2||2.7||2.8||3.5||5.5||6||8||12||14|
Condition of filed and requirements
