• Double Cone 4 Layers Industrial Vacuum Dryer For Strawberry Chips
Double Cone 4 Layers Industrial Vacuum Dryer For Strawberry Chips

Double Cone 4 Layers Industrial Vacuum Dryer For Strawberry Chips

Product Details:

Place of Origin: China
Certification: SGS, CE, ISO
Model Number: FZG

Payment & Shipping Terms:

Minimum Order Quantity: 1unit
Price: USD10990-59000/unit
Packaging Details: shipping container
Delivery Time: 35 working days
Payment Terms: L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram
Supply Ability: 1000unit per year
Get Best Price Contact Now

Detail Information

Name: Vacuum Tray Dryer Material: SUS 304, SUS316L
Type: Static Drying Tray Number: 8-96
Heating Source: Electricity, Hot Water Or Steam Packing: 40HQ Container
High Light:

double cone Industrial Vacuum Dryer


4layers Industrial Vacuum Dryer

Product Description

Low Temperature Industrial Vacuum Dryer Machine For Strawberry Pineapple Apple Chips


ndustrial vacuum dryer working principle
Vacuum drying is to dry the dried material under vacuum. It uses a vacuum pump to pump and dehumidify, so that the working chamber is under vacuum, the drying rate of the material is greatly accelerated, and energy is saved.

Vacuum drying equipment is divided into static dryers and dynamic dryers. YZG round cylinder and FZG square vacuum dryer belong to static vacuum dryer. SZG double cone rotary vacuum dryer is a dynamic dryer. When the material is dried in static drying, the material is in a static state, the shape will not be damaged, and the material can be disinfected before drying. The material is continuously turned and dried during the drying in the dynamic dryer, and the drying is more uniform and sufficient.
The boiling point of the solvent of the material is reduced under vacuum, so it is suitable for drying unstable or heat sensitive materials. The vacuum dryer has good sealing property, so it is suitable for drying the solvent and the material containing strong irritating and toxic gas.
Vacuum drying equipment has been widely used in pharmaceutical, chemical food, dye and other industries, and air meets the "GMP" requirements of drug management regulations.


Questions before quotation:

1. Material name

2. Material initial moisture and final moisture

3. How many kg per batch or per day

4. Heating source is steam or hot water?

​1-- vacuum dryer for drying fruits


2- vacuum dryer for drying food powder

3- vacuum dryer for drying chemical and medicine powder and tablets/pills


Techinical specification:

Model Name YZG-600 YZG-800 YZG-1000 YZG-1400A FZG-10 FZG-15 FZG-20
Inter size of drying chamber(mm) Φ600×976 Φ800×1247 Φ1000×1527 Φ1400×2054 1500×1060 ×1220 1500×1400 ×1220 1500×1800 ×1220
Outer size of drying chamber(mm) 1135×810 ×1024 1700×1045 ×1335 1693×1190 ×150 2386×1675 ×1920 1513×1924 ×1720 1513×1924 ×2060 1513×1924 ×2500
Layers of baking support 4 4 6 8 5 8 12
Interval of baking(mm) 82 82 102 102 122 122 122
Size of baking tray(mm) 310×600 ×45 520×410 ×45 520×410 ×45 460×640 ×45 460×640 ×45 460×640 ×45 460×640 ×45
Quantity of baking tray 4 8 12 32 20 32 48
working pressure inside the pipe of baking support(Mpa) ≤0.784 ≤0.784 ≤0.784 ≤0.784 ≤0.784 ≤0.784 ≤0.784
Operation temperature of baking support, oC 35-150 35-150 35-150 35-150 35-150 35-150 35-150
Degree of vacuum inside the chamber when operation (Mpa) -0.09~0.096
Under the condition of -0.1Mpa and 110oC,evaporation rate of water(kg/m2.hr ) 7.2 7.2 7.2 7.2 7.2 7.2 7.2
When condenser is used,Model,and power of vacuum pump(kw) 2X-15A 2KW 2X-30A 3KW 2X-30A 3KW 2X-70A 5.5KW 2X-70A 5.5KW 2X-70A 5.5KW 2X-90A 2KW
When condenser is not used,Model,and power of vacuum pump(kw) SK-0.8 2.2KW SK-2.7 4KW SK-3 5.5KW SK-6 11KW SK-3 5.5KW SK-6 11KW SK-6 11KW
Weight of drying chamber(kg ) 250 600 800 1400 1400 2100 3200
