GMP Commercial Spray Dryer , Arabic Gum Small Scale Spray Dryer
Product Details:
| Place of Origin: | China |
| Certification: | SGS, CE, ISO |
| Model Number: | LPG-10 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1unit |
|---|---|
| Price: | USD10990-59000/unit |
| Packaging Details: | shipping container |
| Delivery Time: | 25 working days |
| Payment Terms: | L/C, D/A, D/P, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000unit per year |
|
Detail Information |
|||
| Name: | Spray Dryer | Material: | SUS 304, SUS316L |
|---|---|---|---|
| Nozzle: | Centrifugal Atomizer | Evaporation Capacity: | 10KG/HOUR |
| Heating Source: | Electricity | Packing: | 20GP Container |
| Standard: | GMP | Temperature: | 120-300 |
| Highlight: | GMP commercial spray dryer,Arabic Gum small scale spray dryer |
||
Product Description
GMP Standard Industrial Spray Dryer , Centrifugal Spray Drying Machine For Arabic Gum
General Introduction
The high speed centrifugal spray dryer is a type of continuous atmospheric dryer. The liquid material is sprayed in a mist by special equipment to be dried in contact with hot air. It is used to dry some heat-sensitive liquids, suspensions and viscous liquids such as milk, eggs, tannins and medicines. Also used for drying fuels, intermediates, soap powders and inorganic salts.
Spray dryer product features
Spray dryer is also called spray drying machine; Spray dryer is used for small industrial production purpose or for doing experiment, for lab; Big type spray dryer is for mass industrial production of milk powder, protein, blood, chemical, herbal extract, etc
Spray dryer Description
LPG high-speed centrifugal Spray Dryer is applicable for the emulsion, suspension, paste and liquid solution. In polymers and resins, fuels, paints, ceramics, glass type, descaling agent, insecticide, carbohydrates, dairy products, detergents and surfactants, fertilizer, organic compounds and inorganic compounds of dry material, the performance is particularly remarkable. This drier can be widely used into pharmaceutical, chemical, foodstuff and so on industries/field
FAQ
This spray drier is widely used in chemical industry, pharmaceutical industry, foodstuff industry and so on.
1. Material name
2. Content of solid; Content of moisture(%)
3. Processing capacity; Evaporation capacity? (kgs/hour; Litre/ hour)
4. Max. Temperature the material can bear
5. Heating source. Do you need Electric heating compensation to improve heating temperature?
Trial/ Doing Experiment
Spray dryer TECHNICAL PARAMETERS spray dryer
| Spray dryer Parameter |
LPG -5 |
LPG -10 |
LPG -15 |
LPG -20 |
LPG -25 |
LPG -50 |
LPG -100 |
LPG -150 |
LPG -200 |
LPG -500 |
LPG -800 |
LPG -1000 |
LPG -2000 |
LPG -3000 |
LPG -4500 |
LPG -6500 |
| Inlet temperature(°C) | 140-350automaticallycontrolled | |||||||||||||||
| Outlet temperature(°C) | 80-90 | |||||||||||||||
| Water evaporation capacity(kg/h) | 5 | 10 | 15 | 20 | 25 | 50 | 100 | 150 | 200 | 500 | 800 | 1000 | 200 | 3000 | 4500 | 6500 |
| Diameter of atomizing tray (rpm) | 50 | 80 | 80 | 120 | 150 | 180-210 | Decidedin accordance witn the requirementsof processs | |||||||||
| Max Electric heating power(kw) | 12 | 24 | 36 | 45 | 46 | 63 | 81 | 99 | ||||||||
| Dried powder restoring rate(%) | ≥95 | |||||||||||||||
| Length of convered area (m) | 1.6 | 2.7 | 3 | 3.5 | 4 | 4.5 | 5.2 | 7 | 7.5 | 12.5 | 13.5 | 14.5 | Decided in accordance the flow chart, | |||
| Width of convered area (m) | 1.1 | 1.5 | 1.8 | 2 | 2.7 | 2.8 | 3.5 | 5.5 | 6 | 8 | 12 | 14 |
Condition of filed and requirements
|
|||
