Jiangsu Yutong Drying Engineering Co.,ltd 86-519-8890-8088 annieytdryer@163.com
Industrial Atomizing Spray Drying Machine 50-300Degree For Fertilizer LPG 150

Industrial Atomizing Spray Drying Machine 50-300Degree For Fertilizer LPG 150

  • High Light

    300Degree Atomizing Spray Drying Machine

    ,

    LPG 150 Spray Drying Machine

    ,

    50Degree fertilizer dryer machine

  • Type
    Spray Drying Equipment
  • Application
    Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing
  • Condition
    New
  • Voltage
    380/220
  • Power
    As Design
  • Dimension(L*W*H)
    As Design
  • Warranty
    1 Year
  • After-sales Service Provided
    Online Support, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service
  • Weight
    As Design
  • Name
    Spray Dryer
  • Material
    Stainless Steel
  • Installation
    Engineer Guide
  • Heating Source
    Steam+electricity
  • Keywords
    Industrial Dryer
  • Display
    Color LCD Touch Display
  • Controller
    PC Display
  • Spray System
    Centrifugal Nozzle
  • Temperature Range Of Inlet Air
    50 -300 Degree
  • Inner Material
    Mirror Polish Stainless Steel
  • Place of Origin
    Jiangsu, China
  • Brand Name
    YUZHOU
  • Certification
    ISO9001, ISO14001
  • Price
    $1,000.00/Sets
  • Packaging Details
    as per customer's requirement

Industrial Atomizing Spray Drying Machine 50-300Degree For Fertilizer LPG 150

LPG150 Fertilizer Industrial Dryer Atomizing Spray Dryer



FEATURE

Compared to ordinary LPG high-speed atomizing dryer,it has the following features:
(1) Adopted three-grade air filter,the inlet air is one hundred thousand grade.
(2) Adopted wall cooling device,the temperature of inner wall will be on more than 80'C.Even if raw material is
stayed on the wall,it will not be burnt.
(3) Its whole volume is3.5times of standard LPG high-speed atomizing dryer,
(4) Adopted quick washing device,it is can meet the requirements of production for varieties if products.
(5) Adopted wet-dedusting,there is no powder dust out.It is in conformity with the requirements of GMP.
(6) Adopted air sweeping device,the clean effect is satisfied.
(7) Equipped with two sets of atomizer and adopted frequency inventer control.
(8) Adopted PLC control and display,and adapted frequency control,
(9) Equipped with washing device on request,
(10) Adopted the seal transport by dry air on request.



Raw material is feed into the machine from equipment inlet and move forward continuously along with the
horizontal direction under vibratory power.The hot air passes through fluidized-bed and exchange with raw
materials damp,then the wet air is dusted by cyclone separator and exhausted from air outlet,the dried material
is discharged through finished material outlet.
