Professional Centrifugal Whey Protein Powder Spray Dryer Small for Milk Powder

Professional Centrifugal Whey Protein Powder Spray Dryer Small for Milk Powder

Product Details:

Place of Origin: Jiangsu, China
Brand Name: Yuzhou
Certification: ISO14001 ISO9001

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood case or as u requirement
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 100 Set/Sets per Year
Get Best Price Contact Now

Detail Information

Type: Spray Drying Equipment Application: Medicine Processing, Chemicals Processing, Plastics Processing, Food Processing, Battery Industry, Chemical Pharmaceutical Foodstuff Feedstuff
Voltage: 220V 380V 415V 480V After-sales Service Provided: Online Support, No After-sales Service, Video Technical Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service
Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food & Beverage Shops Weight: According The Sitation
Heating Source: Steam+electricity Gas Oil Installation: Engineer Guide
Model: LPG-5~LPG-2000
High Light:

Whey Protein Powder Spray Dryer

,

Centrifugal Milk Powder Spray Dryer

,

480V Spray Drying Machine

Product Description

Professional Centrifugal Whey Protein Powder Spray Dryer Small Milk Powder Spray Dryer

Product Description
Professional high efficiency high speed centrifugal spray dryer work principle
After filtering and heating, the air enters into the hot air distributor at the top of the centrifugal spray dryer, and the hot air will spirally and evenly goes into the drying chamber. The material liquid via high-speed centrifugal atomizer rotates into extremely thin vaporific liquid globule and parallelly flows with the hot air, and then the liquid will be dried into powdery products in a very short time (5-10 seconds). The waste gas after filtering will be expelled through the fan. For the wet organic solvent materials, the spray drying machine can be designed with closed cycle process. It can utilize cyclic nitrogen to dry the materials.

Features
1.LPG centrifugal spray dryer with fast drying speed can constantly evaporate 95%-98% moisture. The drying time is about 5 seconds to 15 seconds. This drying equipment is especially suitable for thermosensitive substance.
2.This spray dryer has excellent uniformity, liquidity and solubility as well as high purity.
3.This spray drying machine has simple production process and easy operation. After drying, it does not need to grind and screen, which can reduce production procedure and enhance the purity.

Model
ZPG-25
ZPG-50
ZPG-80
ZPG-100
ZPG-150
ZPG-200
ZPG-300
Evaporation capacity kg/h
25
50
80
100
150
200
300
Feed capacity kg/h
25-34
50-68
80-108
100-135
150-203
200-270
300-406
Final powder capacity kg/h
4.8-7.2
9.2-14
14.8-22.4
18.4-28
24-42
36.8-56.4
55-85
Solid content %
18-30






Final moisture%
3-5






Electric power kw
63
99
132
153
204
246
330
Heat source
Electric+Steam Gas, As u requirement






Collection method and collection degree
The first cyclone separator and the second cyclone seprator(collection powder)
The bag cloth duster also can helo u collect the powder,but if the material have absorb feature please do not use bag cloth duster.u can use the water film duster can help u solve smell problem.






Inlet temperature degree
160-220






Outlet temperature degree
80-100






Overall dimension(m)
7x4x6.2
8x5x6.9
9.8x5.7x8
11x6.2x8.9
12.2x7x10.75
14.1x7.8x11.9
15x9x13
Professional Centrifugal Whey Protein Powder Spray Dryer Small for Milk Powder 2
Professional Centrifugal Whey Protein Powder Spray Dryer Small for Milk Powder 4

Attention before offering
1. Liquid name and property: solid contents (or water contents), viscosity, surface tension and PH value.
2. Dry powder density, residual water contents allowed, particle size, and maximum temperature allowed.
3. Output, daily shift time.
4. Energy that can be supplied: steam pressure, electricity properly, fuel of coal, oil and natural gas.
5. Control requirement: whether or not the inlet and outlet temperatures should be controlled.
6. Powder-collecting requirement: whether it's necessary to use cloth bag filter and the requirement of the environment of the exhausted gas.


7.Raw material with organic solution?what is it?how many?


Our Company
Professional Centrifugal Whey Protein Powder Spray Dryer Small for Milk Powder 6
Established in 2000, with more than 19 year experience 150 workers 16000 square meter.
With a expertise technical team make machine as customer requirement
With a professional service team will help u installation debugging production in time
Have a laboratory room for the client do trail.
Each yeat the technical team develop 2 new products.
With CE ISO19001 ISO14001more than 100 patents
Annual output value 1.2 Billion.
