12rpm Rotary V Powder Mixer Machine For Herb SGS Certificated

12rpm Rotary V Powder Mixer Machine For Herb SGS Certificated

Product Details:

Place of Origin: China
Certification: SGS ISO CE
Model Number: VHJ

Payment & Shipping Terms:

Minimum Order Quantity: 1units
Price: USD1490-9890 per unit
Packaging Details: plywood or container
Delivery Time: 25 working days
Payment Terms: Western Union, MoneyGram
Supply Ability: 1000units per year
Get Best Price Contact Now

Detail Information

Material: Stainless Steel 304 Or 316L Structure: V
Rotary: Yes Application: Food/pharmaceutical Insudstries
Applicable To: Powder Standard: GMP
Rotary Speed: 12rpm Voltage: 220 380 400 415
High Light:

12rpm Powder Mixer Machine

,

SGS Powder Mixer Machine

Product Description

V Mixer Machine for Food/ Chemical/ Pharmaceutical/ mixing machine for Medicine Powder
​​

V-type powder mixer it is suitable for mixing chemicals, food, medicine, feed, ceramics, metallurgy and other industries powder or granule-like material. Aircraft structure is reasonable, simple to operate airtight, easy access to materials, (manual or vacuum feeding) cylinder made of stainless steel for easy cleaning, it is one of the basic equipment of enterprises.

Description
The machine, food dry powder, mix granular materials.
The unique structure of the mixing drum machine, mixing, high efficiency, no accumulation expected. The whole structure is simple, easy to operate. An outer surface and material contact parts are made of stainless steel, handsome in appearance, maintenance, easy to clean.
Principle and Structure
This machine is equipped with a motor and reducer end, motor power transmitted through a belt gear reducer coupling pass through V-type barrel. So that V-shaped barrel of continuous operation, the material in the barrel to drive the barrel, down, left, right and mixed

V-type mixer Application
Applies to material flow is good, mixing small physical differences particulates, as well as the degree of mixing mixing time is short but requires less demanding material mix, since the material flow within the V-shaped mixing vessel steady, will not damage the materials prototype, Therefore, V-type mixer is also suitable for fragile, easy to wear mix granular materials, or finer particles, massive, comprising mixing the materials with certain moisture, widely used in pharmaceutical, chemical, food and other industries.
Characteristics
The structure of mixing barrel is unique.The mixing effciency is high, no dead corner. The barrel is made of s tainless steel and its internal walls a repolished. The outside qppearance is beautiful. The mixing is uniform, with wide application.


Material to be dried
The mixer is used for mixing the dry material grains in the medical,chemical,food,metallurgical and other industries.

Technical Parameter


specitem
total volume
L
material capcity
L
working capacity
kg
rotating speed
rpm
power
kw
weight
kg
0.05 50 25 15 25 0.55 500
0.15 150 75 45 20 0.75 650
0.3 300 150 90 20 1.1 820
0.5 500 250 150 18 1.5 1250
1 1000 500 300 15 3 1800
1.5 1500 750 450 12 4 2100
2 2000 1000 600 12 5.5 2450
3 3000 1500 900 9 5.5 2980
4 4000 2000 1200 9 7.5 3300
5 5000 2500 1500 8 7.5 3880
6 6000 3000 1800 8 11 4550
8 8000 4000 2400 6 15 5200
10 10000 5000 3000 6 18.5 6000
