Rotary Medicine Dry Powder Mixing Equipment SS 304 Or 316L

Rotary Medicine Dry Powder Mixing Equipment SS 304 Or 316L

Product Details:

Place of Origin: China
Certification: SGS ISO CE
Model Number: SYH

Payment & Shipping Terms:

Minimum Order Quantity: 1units
Price: USD1490-9890 per unit
Packaging Details: plywood or container
Delivery Time: 25 working days
Payment Terms: Western Union, MoneyGram
Supply Ability: 1000units per year
Get Best Price Contact Now

Detail Information

Material: Stainless Steel 304 Or 316L Structure: 3D Dimension Rotary
Rotary: Yes Application: Food/pharmaceutical Insudstries
Applicable To: Powder Standard: GMP
Mixing Effect: Even
High Light:

SS316L dry powder mixing equipment

,

SS304 pharmaceutical powder mixer

Product Description

Medicine Powder Industrial Powder Mixer , Rotary Dry Powder Mixing Equipment



Three-dimensional mixer description
A three-dimensional power mixer is a machine that uniformly mixes two or more materials by mechanical force, gravity, or the like. Hybrid machines are widely used in various industries and daily life. The three-dimensional mixer can mix a variety of materials into a homogeneous mixture, such as mixing cement, sand, gravel and water into concrete wet materials; it can also increase the contact surface area of ​​the material to promote chemical reactions; it can also accelerate physical changes, such as The granular solute is added to the solvent, and the dissolution and mixing can be accelerated by the action of the mixing machine. Commonly used three-dimensional mixers are divided into four categories: gas and low viscosity liquid mixers, medium and high viscosity liquid and paste mixing machines, thermoplastic material mixers, and powdered and granular solid materials mixing machines.


3D powder mixer machine is widely used in the mixing of chemicals, pesticides, dyes, food, feed, building materials, rare earth powders and powders (solid-liquid). The machine has wide adaptability to the mixture material, does not overheat the heat sensitive material, does not pressurize and grind the granular material, and does not produce chip separation phenomenon when the material with different specific gravity and particle size is mixed; the machine according to the process requirements The jacket can be added outside the mixing barrel, and the cooling or heating of the material can be realized by injecting a cold heat medium into the jacket; the cooling is generally pumped into industrial water, and the heating can be steamed or electrically heated.



Technical Parameter

Spec SYH-5 SYH-15 SYH-50 SYH-100 SYH-200 SYH-400 SYH-600 SYH-800 SYH-1000 SYH-1200 SYH-1500 SYH-2000
volume of barrel(L) 5 15 50 100 200 400 600 800 1000 1200 1500 2000
charge volume(L) 4.5 13.5 45 90 180 360 540 720 900 1080 1350 1800
charge weight(kg) 1.5-2.7 4-8.1 15-27 30-54 50-108 100-216 150-324 200-432 250-540 300-648 400-810 500-1080
rotation speed of main shaft(r/min) 0-20 0-20 0-20 0-20 0-15 0-15 0-13 0-10 0-10 0-9 0-9 0-8
motor power(kw) 0.25 0.37 1.1 1.5 2.5 4 5.5 7.5 11 11 15 18.5
size L×W×H(mm) 600
×1000
×1000
800 ×1200
×1000
1150 ×1400
×1000
1250 ×1800
×1550
1450 ×2000
×1550
1650 ×2200
×1550
1850 ×2500
×1750
2100 ×2650
×2000
2150 ×2800
×2100
2000 ×3000
×2260
2300 ×3200
×2500
2500 ×3500
×2800
weight(kg) 100 200 300 800 1200 1200 1500 1700 1800 2000 2400 3000

The bulk density of material is made based on 0.6g/cm3, Please point out if it's over .
