S Shape Blade Powder Mixer Machine Horizontal Ribbon Blender
Product Details:
| Place of Origin: | China |
| Certification: | SGS ISO CE |
| Model Number: | CH |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1units |
|---|---|
| Price: | USD1490-9890 per unit |
| Packaging Details: | plywood or container |
| Delivery Time: | 25 working days |
| Payment Terms: | Western Union, MoneyGram |
| Supply Ability: | 1000units per year |
|
Detail Information |
|||
| Material: | Stainless Steel 304 Or 316L | Structure: | Trough/ribbon |
|---|---|---|---|
| Rotary: | Yes | Application: | Food/pharmaceutical Insudstries |
| Applicable To: | Powder | Standard: | GMP |
| High Light: | s Blade Powder Mixer Machine,Horizontal Powder Mixer Machine |
||
Product Description
High Efficient Powder Mixer Machine Stainless Steel S Shape Blade Horizontal Ribbon Blender
First, the brief introduction of the ribbon blade powder mixer: This equipment is widely used in the dry powder blending of pharmaceutical, food, chemical, electronics and other industries. It is especially suitable for mixing materials with high uniformity and large difference in material specific gravity. The machine has the characteristics of compact structure, simple operation, beautiful appearance, small floor space, convenient cleaning and good mixing effect.
Second, the characteristics of the ribbon blade powder mixer: the equipment is widely used as a whole machine base, the workpieces that are agitated with the slurry and the materials are made of stainless steel, and have good corrosion resistance, can maintain the quality of the mixture, so that The transmission system is flexible and balanced without pollution or discoloration.
Third, the effect of the ribbon blade powder mixer: U-shaped trough has a spiral blade on the slurry shaft to push the material for complex flow, which can achieve good mixing effect.
Fourth, the characteristics of the use of the ribbon blade powder mixer: the material is immersed in the slurry shaft is suitable, after the feeding must be covered with the trough cover, and then drive, so as to avoid the material shallow discharge chute, covered with a mirror basket, can observe Stirring of the material.
Technical Parameter
| capacity(L) | 100 | 150 | 200 | 400 |
| power of motor(kw) | 2.2 | 3 | 3 | 5.5 |
| speed of stirring(rpm) | 24 | 24 | 24 | 24 |
| inclined(×) | 105 | 105 | 105 | 105 |
| weight(kg) | 350 | 500 | 650 | 1200 |
| overall dimensions(mm) | 1400×500×1000 | 1600×600×1100 | 1800×700×1200 | 2000×820×1460 |
The bulk density of material is made based on 0.6g/cm3, Please point out if it's over .
